Stereo-Musikschrank mit Grundig Chassis MS710
Weltfunk GmbH & Co. KG; Mainz
- Country
- Germany
- Manufacturer / Brand
- Weltfunk GmbH & Co. KG; Mainz
- Year
- 1975–1977
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 256885
eBay DE, Privatanzeige aus Hessen-Hanau
eBay DE, Privatanzeige aus Hessen-Hanau
eBay DE, Privatanzeige aus Hessen-Hanau
- Number of Transistors
- 7
- Semiconductors
- B30C100 BF414 AF306 BC308 BF255 BC239 BC239 BC338 TBA120 TCA440 TBA810 TBA810 TCA290 B40C1000
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 9 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220; 240 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Stereo-Musikschrank mit Grundig Chassis MS710 - Weltfunk GmbH & Co. KG; Mainz
- Shape
- Console with Push Buttons.
- Notes
-
Stereo-NF-Verstärker mit 2 Endstufen je 7,5 W;
Rundfunk-Chassis: wie z.B. bei Grundig Mandello 10.
Skalenbeleuchtung 2x 12-15 V, 0,1 A.
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
