801 and Columaire 8

801 and Columaire 8 ; Canadian (ID = 598908) Radio
801 and Columaire 8 ; Canadian (ID = 1319559) Radio 801 and Columaire 8 ; Canadian (ID = 2500511) Radio
801 and Columaire 8 ; Canadian (ID = 1319560) Radio 801 and Columaire 8 ; Canadian (ID = 1319561) Radio
801 and Columaire 8 ; Canadian (ID = 1319562) Radio 801 and Columaire 8 ; Canadian (ID = 1319563) Radio
801 and Columaire 8 ; Canadian (ID = 1319564) Radio 801 and Columaire 8 ; Canadian (ID = 1319565) Radio
801 and Columaire 8 ; Canadian (ID = 2500434) Radio 801 and Columaire 8 ; Canadian (ID = 2500436) Radio
Use red slider bar for more.
801 and Columaire 8 ; Canadian (ID = 1319559) Radio
Canadian: 801 and Columaire 8 [Radio] ID = 1319559 517x1400
Select picture or schematic to display from thumbnails on the right and click for download.
For model 801 and Columaire 8, Canadian Westinghouse, Hamilton:
eBay 271084197485, seller zhakos, Everett, Washington, USA.

Country:  Canada
Manufacturer / Brand:  Canadian Westinghouse, Hamilton
alternative name

Westinghouse Canada
Year: 1931/1932 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 235 UY227 UY224 235 UY227 UX245 UX245 UX280
Main principle Superhet with RF-stage; ZF/IF 175 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 801 and Columaire 8 - Canadian Westinghouse,
Material Wooden case
Shape Grandfather Clock with Radio.
Notes

Careful, there is also the same cabinet for a TRF radio!

Circuit diagram reference Radio College of Canada
Literature/Schematics (1) Westinghouse page 11

Model page created by Dirk Taekels. See "Data change" for further contributors.



All listed radios etc. from Canadian Westinghouse, Hamilton
Here you find 355 models, 146 with images and 333 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
