- Country
- United States of America (USA)
- Manufacturer / Brand
- Wilcox-Gay Corp.; Charlotte (MI)
- Year
- 1946
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 66754
-
- Brand: Recordio
Beitman
Beitman
from ebay
from ebay
from ebay
from ebay
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Details
- Recording phonogr.-Disc Recorder
- Power type and voltage
- Alternating Current supply (AC) / 105 - 125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.25 inch = 15.9 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 6B30 - Wilcox-Gay Corp.; Charlotte MI
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 19 x 12.5 x 15 inch / 483 x 318 x 381 mm
- Notes
- 6B10 Late, 6B20, 6B30, 6B40 & 6B42 are the same except for the following: 6E5 is tuning eye while a 6U6 was used as tuning eye in early models. 6SJ7GT replaced the 6J7GT on early models.
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 15 = 1947 and before
- Mentioned in
- Radio Retailing (Radio & Television R.) (April 1946 page 115. June 1946 page 37.)
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Dat 11-46, set 8, folder 468-27)
