Bryce Ringwood, South Africa - Tube collection

Information - Help
ID = 8156
Photo Bryce Ringwood

Below you find a part of the tube collection Bryce Ringwood.

For reasons of space have to keep the collection down to a few. I repair vintage radios as a paying hobby. I keep records of them for interest. Call sign used to be G8ARY many years ago when I lived in UK. I began my hobby by building a crystal set radio using Ivalek headphones, Repanco coil and Jackson Bros variable capacitor (which I still have!). It really didn't work very well. I used to listen to short wave on my Dad's radio and later on a Wireless Set No. 19. I tried without success to receive the first Sputnik using an R208 receiver on 20 and 40 MHz. I built my own receivers and transmitters for the amateur 70cm band and had a contact from Leeds in the UK with a Norwegian station using my 4X150A homebrew transmitter. Before leaving England for South Africa, I hurriedly built a five band shortwave receiver to listen to the BBC. On arrival, I more or less gave up radio for 20 years until a colleague presented me with a very broken NC 100. (Meanwhile, I had been very busy making electronic equipment for strain measurement and helping my children with radio control.) The NC 100 seems to have acted like a magnet, attracting all sorts of strange equipment to make a collection of sorts. My Wife bought the Phantom de Luxe for my Birthday.
Result: 1 to 16 from 16




Sort order:  [ Name | Maker | Year | Type | Country ]

Excerpt from the tube collection of Bryce Ringwood. These images (tube photos) were uploaded to the respective tubes or valves by Bryce Ringwood.

Construction is 'turned round' compared to a normal triode, in other words heater, grid and anode are in the horizontal plane of the photograph.
A2521
MO Valve Co. Ltd.; GB GB
click to access the tube page
CV263
Ediswan, Siemens Edison Swan... GB
click to access the tube page
CV2220
click to access the tube page
CV2243
click to access the tube page
CV4064
Common type Worldwide tube/s... ZZ
This looks exactly like the old schematics for a diode.
DCG1/250
click to access the tube page
DET23
GEC, General Electric Co Ltd... GB
I made the tube glow with a UV LED. I remember these being used in a popular tape recorder of the '50s
DM70 1952
Common type Europe tube/semi... EU
Incredibly small - but larger than a hearing aid valve.
DM160
Common type Europe tube/semi... EU
Mullard EC1000
EC1000
Mullard Radio Valve Co. Ltd.; GB
click to access the tube page
EF732
Valvo GmbH, Radioröhrenfabri... D
This tube needs to be kept absolutely clean and free from contamination, in common with all electrometer valves. Mullard supplied it in a large carton with the tube inside the sealed cellophane bag shown here.
ME1403
Mullard Radio Valve Co. Ltd.; GB
click to access the tube page
V246/1K
Standard Telephones and Cabl... GB
Special quality quick-heat version of the QQV06-40. Note the gold pins.
YL1030
click to access the tube page
ZA1002
Common type Europe tube/semi... EU
This must be a spare for an Eddystone 770/U.
6AM4
Common type Worldwide tube/s... ZZ

Result: 1 to 16 from 16





Tube collector page of valve collector Bryce Ringwood as «own HP at RMorg»
As a member of Radiomuseum.org Bryce Ringwood displays items in his/her tube collection. Tubes are called valves in British oriented countries.
Valve and tube collectors as well as radio collectors are invited to join Radiomuseum.org. Every member can display separate collections of tubes, radios etc.

Bryce Ringwood started his/her tube collection (valve collection) here on 14.Jun.2008. [index-en]
