35A5

Information - Help
ID = 3715

Country:
Worldwide
Brand:
Developer: Philco, Philadelphia Stg. Batt. Co.; USA
Tube type:  Beam Power Tube   Power/Output
Identical to 35A5 = CV1753
Similar Tubes
Normally replaceable-slightly different:
  35A5E
Heater different:
  7A5
Other base:
  35L6GT
Other base and data slightly different:
  35C5
First Source (s)
09.Dec.1938 : Electron Tube Registration List 152
Predecessor Tubes 35L6GT
Successor Tubes 35C5   35B5

Base Loctal-8, B8G (Sylvania, 1938) (Codex=Wdb)
Was used by Radio/TV-reception etc.
Filament Vf 35 Volts / If 0.15 Ampere / Indirect / Series, AC/DC
Tube prices 2 Tube prices (visible for members only)
Information source Essential Characteristics, GE 1973
Taschenbuch zum Röhren-Codex 1948/49
  35A5: Courtesy Bureau Belper (De Muiderkring, Bussum), Scan Frank Philipse
Karel De Reus †

35A5: Photo of tube from my collection - TS
Tomasz Szczesniak


35A5: Telefunken Werkstattbuch
Wolfgang Bauer


35A5: Sylvania Technical Manual
Peter Hoddow


from Just Qvigstad

Usage in Models 1= 1924? ; 13= 1938 ; 1= 1939? ; 55= 1939 ; 1= 1940? ; 19= 1940 ; 14= 1941 ; 3= 1945? ; 4= 1945 ; 20= 1946? ; 39= 1946 ; 5= 1947?? ; 6= 1947? ; 8= 1947 ; 13= 1948 ; 1= 1949?? ; 3= 1949? ; 1= 1949 ; 2= 1950?? ; 1= 1950? ; 1= 1950 ; 9= 1951?? ; 6= 1951 ; 1= 1952 ; 3= 1953 ; 2= 1954 ; 2= 1955?

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):234
