AC101

Information - Help
ID = 13723

Country:
Germany
Brand: Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Tube type:  Triode, vacuum   Universal
Identical to AC101 = KL70581
Similar Tubes
Other base:
  AC100
First year 1939 -- Collector info (Sammler)

Base Europe 5-Pin (O5A, B5) (Codex=Fa) Top contact with a cap
Was used by Technology / Measurement
Filament Vf 4 Volts / If 0.65 Ampere / Indirect / Parallel, (AC/DC) /
Literature Taschenbuch zum Röhren-Codex 1948/49

  AC101: Röhrenkartei Drenkelfort
Peter Hoddow

AC101: H.H.
Heinz Höger


AC101: RTT 1974 (Franzis) 13. Auflage
Martin Renz


AC101: Telefunken 1944
Robert Schmalstieg
