SDA9255

Information - Help
ID = 68020

Country:
Germany
Brand: Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
Tube type:  IC - Integrated Circuit
Identical to SDA9255

Base Wires
Description

Aufbau/Content: IC (CMOS);
Form/Case/Outline: QFP-64;
Type/Application: SRC Scan Rate Converter, I²C-Bus Control (400 kHz);
Daten/electr.data: Vcc: 5 V; Icc: <200 mA; Pd: <__ mW; t op: 0...70 °C;
-


Dimensions (WHD)
incl. pins / tip
17 x 2 x 17 mm / 0.67 x 0.08 x 0.67 inch
Weight 1 g / 0.04 oz
Information source - - Manufacturers Literature

SDA9255: Siemens
Günther Stabe † 19.8.20

sda9255_s.png SDA9255: Siemens
Günther Stabe † 19.8.20

SDA9255: Siemens
Günther Stabe † 19.8.20
