4-56W; AEG Radios Allg. (ID = 3850) Radio
AEG Radios Allg.: 4-56W [Radio] ID = 3850 697x442
Select picture or schematic to display from thumbnails on the right and click for download.
For model 4-56W, AEG (Radios) Allg.Elektricitäts-Ges.

Country:  Germany
Manufacturer / Brand:  AEG (Radios) Allg.Elektricitäts-Ges.
Year: 1936/1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ACH1 AF7 ABC1 AL1 AZ1
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 4-56W - AEG Radios Allg.Elektricitäts-
Material Wooden case
Dimensions (WHD) 575 x 310 x 295 mm / 22.6 x 12.2 x 11.6 inch
Net weight (2.2 lb = 1 kg) 16.5 kg / 36 lb 5.5 oz (36.344 lb)
Price in first year of sale 275.00 RM
Collectors' prices
Source of data Radio-Zentrale Prohaska 1936/37 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
