Bimby Luxus hell

Bimby Luxus ; AEG Radios Allg. (ID = 50997) Radio

Bimby Luxus ; AEG Radios Allg. (ID = 50998) Radio
Bimby Luxus ; AEG Radios Allg. (ID = 2040191) Radio Bimby Luxus ; AEG Radios Allg. (ID = 1010509) Radio
Use red slider bar for more.
Bimby Luxus ; AEG Radios Allg. (ID = 2040191) Radio
AEG Radios Allg.: Bimby Luxus [Radio] ID = 2040191 1321x791
Select picture or schematic to display from thumbnails on the right and click for download.
For model Bimby Luxus hell, AEG (Radios) Allg.Elektricitäts-Ges.:
Eigenes Gerät, soeben gekauft im ebay - jedoch nicht für meine Sammlung gedacht

Country:  Germany
Manufacturer / Brand:  AEG (Radios) Allg.Elektricitäts-Ges.
Year: 1962/1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM84 EL95
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Bimby Luxus [hell] - AEG Radios Allg.Elektricitäts-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 390 x 215 x 185 mm / 15.4 x 8.5 x 7.3 inch
Notes
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Price in first year of sale 305.00 DM
External source of data Erb
Source of data Handbuch VDRG 1962/1963
