Magnetophon KL65TU

Magnetophon KL65TU; AEG Radios Allg. (ID = 11759) R-Player
Magnetophon KL65TU; AEG Radios Allg. (ID = 921982) R-Player Magnetophon KL65TU; AEG Radios Allg. (ID = 921983) R-Player
Magnetophon KL65TU; AEG Radios Allg. (ID = 921984) R-Player Magnetophon KL65TU; AEG Radios Allg. (ID = 921985) R-Player
Magnetophon KL65TU; AEG Radios Allg. (ID = 921986) R-Player Magnetophon KL65TU; AEG Radios Allg. (ID = 921987) R-Player
Use red slider bar for more.
Magnetophon KL65TU; AEG Radios Allg. (ID = 921982) R-Player
AEG Radios Allg.: Magnetophon KL65TU [R-Player] ID = 921982 933x690
Select picture or schematic to display from thumbnails on the right and click for download.
For model Magnetophon KL65TU, AEG (Radios) Allg.Elektricitäts-Ges.

Country:  Germany
Manufacturer / Brand:  AEG (Radios) Allg.Elektricitäts-Ges.
Year: 1956/1957 Category: Sound/Video Recorder and/or Player
Valves / Tubes 4: EF86 ECC83 ECC81 EM71a
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder; Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Magnetophon KL65TU - AEG Radios Allg.Elektricitäts-
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 310 x 135 x 240 mm / 12.2 x 5.3 x 9.4 inch
Notes Zweispur; Bandgeschwindigkeit 9,5 cm/s.; Spulen-Ø 13 cm.
Baugleich mit Telefunken KL65TU.
Net weight (2.2 lb = 1 kg) 7.4 kg / 16 lb 4.8 oz (16.3 lb)
Price in first year of sale 455.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1956/57
