425D; Albis, Albiswerke AG (ID = 1332722) Radio
Albis, Albiswerke AG: 425D [Radio] ID = 1332722 872x542
Select picture or schematic to display from thumbnails on the right and click for download.
For model 425D, Albis, Albiswerke AG (Siemens Switzerland AG / Telefunken Zürich AG / Siemens-Albis); Albisrieden

Country:  Switzerland
Manufacturer / Brand:  Albis, Albiswerke AG (Siemens Switzerland AG / Telefunken Zürich AG / Siemens-Albis); Albisrieden
Year: 1941/1942 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EF13 ECH11 EBF11 EF11 EM4 EL12 AZ12
Main principle Superhet with RF-stage; ZF/IF 471 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details Wired Wireless Receiver(AF only)
Power type and voltage Alternating Current supply (AC)
Loudspeaker Presumably Dynamic Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 425D - Albis, Albiswerke AG Siemens
Material Wooden case
Dimensions (WHD) 665 x 260 x 410 mm / 26.2 x 10.2 x 16.1 inch
Notes Aut.BBr., Heimatstil!
Price in first year of sale 680.00 SFr
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Thali-Schemasammlung und Tungsram-Röhrenbestückung.
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.


All listed radios etc. from Albis, Albiswerke AG (Siemens Switzerland AG / Telefunken Zürich AG / Siemens-Albis); Albisrieden
Here you find 165 models, 134 with images and 136 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
