833; Asa, Turku (ID = 932094) Radio
Asa, Turku: 833 [Radio] ID = 932094 922x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model 833, Asa, Turku
Country:  Finland
Manufacturer / Brand:  Asa, Turku
Year: 1956 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EC92 EC92 EF85 ECH81 EM80 EABC80 EL84
Main principle Superheterodyne (common); ZF/IF 485/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Model: 833 - Asa, Turku
Material Wooden case
Shape Tablemodel with Push Buttons.

Model page created by Timo Rantasaari. See "Data change" for further contributors.
