Grand Prix Present 610K (S.174 610 K)

Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1134902) Radio

Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1134904) Radio

Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1134905) Radio

Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1134908) Radio
Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1551591) Radio Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1134900) Radio
Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1576508) Radio Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1576509) Radio
Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1576510) Radio Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1576512) Radio
Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1576513) Radio
Use red slider bar for more.
Grand Prix Present 610K ; Bang & Olufsen B&O; (ID = 1551591) Radio
Bang & Olufsen B&O;: Grand Prix Present 610K [Radio] ID = 1551591 872x304
Select picture or schematic to display from thumbnails on the right and click for download.
For model Grand Prix Present 610K (S.174 610 K), Bang & Olufsen (B&O); Struer:
Katalog Österreich, 1963

Country:  Denmark
Manufacturer / Brand:  Bang & Olufsen (B&O); Struer
Brand

B&O
Year: 1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 11: ECC85 ECH81 EF89 EBF89 EM84a ECC83 ECC83 ECL86 ECL86 ECL86 ECL86
Main principle Superheterodyne (common); ZF/IF 444/10700 kHz; 4 AF stage(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out 14 W (max.)
from Radiomuseum.org Model: Grand Prix Present 610K - Bang & Olufsen B&O; Struer
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 800 x 241 x 262 mm / 31.5 x 9.5 x 10.3 inch
Notes

Technisch entsprechend Grand Prix 610 Moderne, aber mit im Gehäuse eingebauten Lautsprechern (oval, 21 x 16 cm).

Stereodecoder (nachrüstbar) 950 ATS

Net weight (2.2 lb = 1 kg) 16 kg / 35 lb 3.9 oz (35.242 lb)
Price in first year of sale 6'990.00 ATS
Source of data -- Original-techn. papers.

Model page created by Fritz Czapek † 29.9.17. See "Data change" for further contributors.
