Mexico ; Becker, Max Egon, (ID = 1032180) Car Radio
Becker, Max Egon,: Mexico [Car Radio] ID = 1032180 933x651
Select picture or schematic to display from thumbnails on the right and click for download.
For model Mexico, Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim:
Gerät ist im Rundfunk Museum der Stadt Fürth ausgestellt.

Country:  Germany
Manufacturer / Brand:  Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim
Year: 1953–1956 Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 8: ECC81 ECH81 EF85 EBF80 EABC80 EBF80 ECC81 EL84
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details Radio Control (+Remote Wire etc)
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 3.7 W (unknown quality)
from Radiomuseum.org Model: Mexico - Becker, Max Egon,
Material Metal case
Shape Chassis only or for «building in»
Notes 2-teilig; automatische Sendereinstellung.
Price in first year of sale 585.00 DM
External source of data E. Erb 3-907007-36-0
Source of data Kat.d.Rundf.GrossH.1953/54 / Radiokatalog Band 2, Ernst Erb


All listed radios etc. from Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim
Here you find 299 models, 209 with images and 157 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Becker, Max Egon,: Mexico
Threads: 1 | Posts: 4
Hits: 1838     Replies: 3
becker: Becker Mexico "wonder bar" not stopping at stations
Jeff Miller
04.Dec.14
  1

Greetings,

A friend in Beirut has a 1961 Mercedes-Benz Type 180b with a Becker Mexico. It was working fine for years, but now it passes by all the stations/signals. He said, "All was working fine except that the "wonder bar" did not detect any stations. It kept going to the right, then rewinding, then back to the right, and never stopped until the radio was turned off."

He just took it to a technician who replaced "a few capacitors", but the problem is the same.

Can someone please advise me what to tell him to look at (which part of the schema, etc.)?

This is the earlier Becker Mexico with the clockwork mechanism.

Thank you,

Jeff


Jeff Miller
04.Dec.14
  2

Update: He replaced a 3 ohm resistor that measured 0 ohms and the radio is working again. No idea which resistor it was. Thanks for reading.

Jeff

Jeff Miller
06.Dec.14
  3

What is the value range for variable capacitor C126 "2/10"? See attached photo and schematic.

Attachments

Jeff Miller
06.Dec.14
  4

Found it. Spare parts list says "2/10 MMF" (2-10 pF).
