Radiobell RB313D

Bell Telephone Mfg. Co. (Radiobell); Antwerp

Data
Forum
Pictures
Collections

  • Year
  • 1954/1955
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 271163
    • Brand: Radiobell

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superheterodyne (common); 2 AF stage(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 115; 125; 135; 150; 220; 250 Volt
  • Loudspeaker
  • 3 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Radiobell RB313D - Bell Telephone Mfg. Co.
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 552 x 363 x 245 mm / 21.7 x 14.3 x 9.6 inch
  • Notes

  • 4 push buttons. AM and FM antenna built-in. Progressive tone control. 3 speakers: 15 cm (front) and two elliptical 18 x 10 cm (sides) .

    4 band radio with LW, BC (MW), SW (18-51 m) and FM (88-100 MHz).

    Cabinet in polished walnut.

    See also the comparable model RB312, probably having the same chassis.



  • Price in first year of sale
  • 4,495.00 BEF
  • Mentioned in
  • -- Original prospect or advert
