X (unknown)
Ben-Gal (Bengal); Rishon Le Zion
- Pays
- Israël
- Fabricant / Marque
- Ben-Gal (Bengal); Rishon Le Zion
- Année
- 1960 ??
- Catégorie
- Radio - ou tuner d'après la guerre 1939-45
- Radiomuseum.org ID
- 362837
- No. de tubes
- 7
- Principe général
- Super hétérodyne avec étage HF; FI/IF 455 kHz; 2 Etage(s) BF
- Circuits accordés
- 7 Circuits MA (AM)
- Gammes d'ondes
- PO, GO et plus que 2 x OC
- Tension / type courant
- Alimentation Courant Alternatif (CA) / 220 Volt
- Haut-parleur
- HP dynamique à aimant permanent + bobine mobile
- Matière
- Boitier en bois
- De Radiomuseum.org
- Modèle: X - Ben-Gal Bengal; Rishon Le Zion
- Forme
- Modèle de table profil bas (grand modèle).
- Dimensions (LHP)
- 600 x 360 x 280 mm / 23.6 x 14.2 x 11 inch
- Remarques
-
The receiver has 8 spreaded short wave bands, achieved by moving variable capacitor and short wave coils cores. See detailed photos of the bottom chassis. There is a cable on the variable capacitor shaft, moving the coil cores against a spring.
- Poids net
- 10.5 kg / 23 lb 2 oz (23.128 lb)
- Auteur
- Modèle crée par Karol Gillon. Voir les propositions de modification pour les contributeurs supplémentaires.
