For model Amazonas 42900 Serie T, Blaupunkt (Ideal), Berlin, später Hildesheim:
credit photo roger & andrée bertin

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1962 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM87 EL84 ECL86
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 155; 220 Volt
Loudspeaker 4 Loudspeakers
Power out 6 W (unknown quality)
from Radiomuseum.org Model: Amazonas 42900 Serie T - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Console: Chairside Radio.
Notes "Stereo Truhe".
Consommation 75 watts. Antenne dipôle FM. Cadre ferrite pour PO GO.
2 haut-parleurs suprakustik ovale 260*180mm. 2 haut-parleurs suprakustik diamètre 100 mm.
Changeur de disques PE66 pour 16; 33; 45 et 78 tours. 2 sorties suplémentaire pour HP. 1 entrée suplémentaire pour magnétophone.
Source of data - - Data from my own collection
Literature/Schematics (1) -- Schematic (schéma documentation technique mode d'emploi)

Model page created by Roger Bertin. See "Data change" for further contributors.
