B174U

B174U; Blaupunkt Ideal, (ID = 1883292) Radio

B174U; Blaupunkt Ideal, (ID = 1883293) Radio

B174U; Blaupunkt Ideal, (ID = 11076) Radio

B174U; Blaupunkt Ideal, (ID = 1892349) Radio

B174U; Blaupunkt Ideal, (ID = 1892350) Radio

B174U; Blaupunkt Ideal, (ID = 1892351) Radio

B174U; Blaupunkt Ideal, (ID = 1892352) Radio

B174U; Blaupunkt Ideal, (ID = 1892353) Radio

B174U; Blaupunkt Ideal, (ID = 1892354) Radio
B174U; Blaupunkt Ideal, (ID = 352816) Radio B174U; Blaupunkt Ideal, (ID = 352818) Radio
Use red slider bar for more.
B174U; Blaupunkt Ideal, (ID = 352816) Radio
Blaupunkt Ideal,: B174U [Radio] ID = 352816 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model B174U, Blaupunkt (Ideal), Berlin, später Hildesheim:
Eigene Sammlung

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1950/1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH11 UBF11 UCL11 UY11
Main principle Superheterodyne (common); ZF/IF 473 kHz
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage AC/DC-set / 110/225 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: B174U - Blaupunkt Ideal, Berlin,
Material Bakelite case
Dimensions (WHD) 420 x 250 x 200 mm / 16.5 x 9.8 x 7.9 inch
Notes Ind.A;Aud.;auch 4 Rö
Price in first year of sale 165.00 DM
Source of data Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange Schaltungen der Funkindustrie, Buch 2
Mentioned in Funk-Technik (FT) (5023)
