Java F2154 Ausfg. B

Java F2154; Blaupunkt Ideal, (ID = 251856) Television

Java F2154; Blaupunkt Ideal, (ID = 251857) Television

Java F2154; Blaupunkt Ideal, (ID = 251858) Television

Java F2154; Blaupunkt Ideal, (ID = 381822) Television

Java F2154; Blaupunkt Ideal, (ID = 381823) Television

Java F2154; Blaupunkt Ideal, (ID = 381824) Television
Java F2154; Blaupunkt Ideal, (ID = 458159) Television Java F2154; Blaupunkt Ideal, (ID = 458162) Television
Java F2154; Blaupunkt Ideal, (ID = 458161) Television Java F2154; Blaupunkt Ideal, (ID = 308918) Television
Java F2154; Blaupunkt Ideal, (ID = 458164) Television Java F2154; Blaupunkt Ideal, (ID = 458168) Television
Java F2154; Blaupunkt Ideal, (ID = 458175) Television Java F2154; Blaupunkt Ideal, (ID = 458182) Television
Java F2154; Blaupunkt Ideal, (ID = 458187) Television Java F2154; Blaupunkt Ideal, (ID = 458188) Television
Use red slider bar for more.
Java F2154; Blaupunkt Ideal, (ID = 458159) Television
Blaupunkt Ideal,: Java F2154 [Television] ID = 458159 826x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Java F2154 Ausfg. B, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1954/1955 Category: Television Receiver (TV) or Monitor
Valves / Tubes 17: PCC84 ECC81 EF80 EF80 EF80 EAA91 PL83 EF80 PABC80 PL82 ECL80 PCL81 ECC81 PL81 PY83 EY51 MW43-61
Main principle Superheterodyne (common); ZF/IF 25500 kHz; 2 AF stage(s)
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Java F2154 [Ausfg. B] - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 580 x 470 x 570 mm / 22.8 x 18.5 x 22.4 inch
Notes 10 VHF-Kanäle. Kanalwähler mit "Spulenfahrstuhl".
Frühe Geräte haben auch elektrodynamischen (fremderregten) Lautsprecher.
Bildröhre auch Bmv42-2 Fernseh-GmbH, beide Bildröhrentypen haben zylindrische Schirmfläche.
Net weight (2.2 lb = 1 kg) 29 kg / 63 lb 14 oz (63.877 lb)
Price in first year of sale 998.00 DM
External source of data Erb
Source of data Rundfunk- und Fernseh-Katalog 1954/55
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Lange, Schaltungen der Funkindustrie
