Riviera 2540 dunkel

Riviera 2540; Blaupunkt Ideal, (ID = 109909) Radio

Riviera 2540; Blaupunkt Ideal, (ID = 109911) Radio

Riviera 2540; Blaupunkt Ideal, (ID = 109912) Radio

Riviera 2540; Blaupunkt Ideal, (ID = 109913) Radio

Riviera 2540; Blaupunkt Ideal, (ID = 109915) Radio

Riviera 2540; Blaupunkt Ideal, (ID = 109917) Radio

Riviera 2540; Blaupunkt Ideal, (ID = 109918) Radio

Riviera 2540; Blaupunkt Ideal, (ID = 109920) Radio

Riviera 2540; Blaupunkt Ideal, (ID = 11318) Radio
Riviera 2540; Blaupunkt Ideal, (ID = 314704) Radio Riviera 2540; Blaupunkt Ideal, (ID = 314705) Radio
Riviera 2540; Blaupunkt Ideal, (ID = 26108) Radio Riviera 2540; Blaupunkt Ideal, (ID = 145290) Radio
Riviera 2540; Blaupunkt Ideal, (ID = 108887) Radio Riviera 2540; Blaupunkt Ideal, (ID = 820428) Radio
Riviera 2540; Blaupunkt Ideal, (ID = 820432) Radio Riviera 2540; Blaupunkt Ideal, (ID = 1796300) Radio
Use red slider bar for more.
Riviera 2540; Blaupunkt Ideal, (ID = 314704) Radio
Blaupunkt Ideal,: Riviera 2540 [Radio] ID = 314704 700x436
Select picture or schematic to display from thumbnails on the right and click for download.
For model Riviera 2540 dunkel, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1958/1959 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: ECC85 EF89 ECH81 EF89 EM84 EABC80 ECC82 EL95 EL95
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle Super-Heterodyne (Super in general); ZF/IF 460 kHz
Tuned circuits 7 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110, 127, 155, 220, 240 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Riviera 2540 [dunkel] - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 620 x 388 x 283 mm / 24.4 x 15.3 x 11.1 inch
Notes Empfangsteil mit KW-Lupe / Lautsprecher: 1 Suprakustik oval mit Hochtonkegel, 2 perm.-dyn. Seitenlautspr. / Gehäuse, nußbaum dunkel
Net weight (2.2 lb = 1 kg) 13.3 kg / 29 lb 4.7 oz (29.295 lb)
Price in first year of sale 420.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1958/59


All listed radios etc. from Blaupunkt (Ideal), Berlin, später Hildesheim
Here you find 3130 models, 2781 with images and 2122 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
