Riviera MX Stereo Console 2633 USA
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1959/1960
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 147492
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Main principle
- Superhet with RF-stage; ZF/IF 460/10700 kHz; Export model
- Tuned circuits
- 7 AM circuit(s) 12 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 105-120 Volt
- Loudspeaker
- 6 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Riviera MX Stereo Console 2633 USA - Blaupunkt Ideal, Berlin,
- Shape
- Console with Push Buttons.
- Dimensions (WHD)
- 52 x 31.5 x 15.5 inch / 1321 x 800 x 394 mm
- Notes
-
U.S. export model with FM up to 108 MHz, SW bandspread. AF stereo. Printed circuit board.
Recod changer = PE Rex Deluxe Stereo.
- Net weight (2.2 lb = 1 kg)
- 56 kg / 123 lb 5.6 oz (123.348 lb)
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Ashis Mukerjea. See "Data change" for further contributors.
