Roma AS 73259
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1963/1964
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 265555
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
Q: Blaupunkt, Service-Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 15
- Number of Transistors
- 2
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Roma AS 73259 - Blaupunkt Ideal, Berlin,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 690 x 495 x 360 mm / 27.2 x 19.5 x 14.2 inch
- Notes
-
Abmesseung Tiefe + 25 mm für Tubus.
Lautsprecher 210 x 150 und D= 70 mm.Siehe auch Blaupunkt Roma AS 73250
- Net weight (2.2 lb = 1 kg)
- 31 kg / 68 lb 4.5 oz (68.282 lb)
- Mentioned in
- Handbuch VDRG 1963/1964
- Author
- Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
