Sultan 2620 dunkel

Sultan 2620; Blaupunkt Ideal, (ID = 23328) Radio

Sultan 2620; Blaupunkt Ideal, (ID = 23330) Radio

Sultan 2620; Blaupunkt Ideal, (ID = 23331) Radio

Sultan 2620; Blaupunkt Ideal, (ID = 1337548) Radio

Sultan 2620; Blaupunkt Ideal, (ID = 1337549) Radio

Sultan 2620; Blaupunkt Ideal, (ID = 1337550) Radio

Sultan 2620; Blaupunkt Ideal, (ID = 1337551) Radio

Sultan 2620; Blaupunkt Ideal, (ID = 1337552) Radio

Sultan 2620; Blaupunkt Ideal, (ID = 1337553) Radio

Sultan 2620; Blaupunkt Ideal, (ID = 1827033) Radio
Sultan 2620; Blaupunkt Ideal, (ID = 480498) Radio Sultan 2620; Blaupunkt Ideal, (ID = 480499) Radio
Sultan 2620; Blaupunkt Ideal, (ID = 480500) Radio Sultan 2620; Blaupunkt Ideal, (ID = 109605) Radio
Sultan 2620; Blaupunkt Ideal, (ID = 111205) Radio Sultan 2620; Blaupunkt Ideal, (ID = 210655) Radio
Sultan 2620; Blaupunkt Ideal, (ID = 480501) Radio Sultan 2620; Blaupunkt Ideal, (ID = 480502) Radio
Sultan 2620; Blaupunkt Ideal, (ID = 480503) Radio Sultan 2620; Blaupunkt Ideal, (ID = 493793) Radio
Use red slider bar for more.
Sultan 2620; Blaupunkt Ideal, (ID = 480498) Radio
Blaupunkt Ideal,: Sultan 2620 [Radio] ID = 480498 712x519
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sultan 2620 dunkel, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1959/1960 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM84 EL84
Main principle Super-Heterodyne (Super in general); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110, 127, 155, 220, 240 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Sultan 2620 [dunkel] - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 540 x 355 x 240 mm / 21.3 x 14 x 9.4 inch
Notes dunkel
Net weight (2.2 lb = 1 kg) 9.7 kg / 21 lb 5.9 oz (21.366 lb)
Price in first year of sale 289.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1959/60
