Virginia 2530; Blaupunkt Ideal, (ID = 150590) Radio
Blaupunkt Ideal,: Virginia 2530 [Radio] ID = 150590 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model Virginia 2530 dunkel, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1958/1959 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 EF89 ECH81 EF89 EM84 EABC80 EL84
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle Superhet with RF-stage; ZF/IF 460 kHz
Tuned circuits 7 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110, 127, 155, 220, 240 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Virginia 2530 [dunkel] - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 620 x 375 x 285 mm / 24.4 x 14.8 x 11.2 inch
Notes Drehbare Ferrit-Antenne für MW und LW / KW-Lupe / Lautsprecher: 1 Front-LS 260 x 180 mm - 2 Seiten-LS 100 mm / Gehäuse in Nußbaum dunkel
Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)
Price in first year of sale 370.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1958/59
