For model Clairtone RT-20C Ch= RC31-C, Braun; Frankfurt:
Ebay-Verk.: streifenfilter, ArtNr.: 120813786847

Country:  Germany
Manufacturer / Brand:  Braun; Frankfurt
Year: 1962 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECC85 or 6AQ8 ECH81 or 6AJ8 EF89 or 6DA6 EABC80 or 6AK8 EL84 or 6BQ5
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Clairtone RT-20C Ch= RC31-C - Braun; Frankfurt
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 500 x 255 x 180 mm / 19.7 x 10 x 7.1 inch
Notes Similar to the domestic Braun RT20.
UKW/FM 88...108 MHz.
Net weight (2.2 lb = 1 kg) 7.6 kg / 16 lb 11.8 oz (16.74 lb)
Source of data -- Collector info (Sammler)
Literature/Schematics (1) Photofact Folder, Howard W. SAMS

Model page created by Bernhard Nagel. See "Data change" for further contributors.
