Junior 5 (coin)
Capehart Corp.; Fort Wayne, IN - see also Farnsworth
- Country
- United States of America (USA)
- Manufacturer / Brand
- Capehart Corp.; Fort Wayne, IN - see also Farnsworth
- Year
- 1931/1932
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 35037
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Jukebox-Coin operated Phonograph
- Power type and voltage
- Alternating Current supply (AC) / 110 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Junior 5 - Capehart Corp.; Fort Wayne, IN
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 25.25 x 42.5 x 17.75 inch / 641 x 1080 x 451 mm
- Notes
-
Capehart model Junior 5 with "10-12" changer
This model 5 is a coin operated record changer with the simple drop system "10-12" and the model 6 is the same without coin operation. Both have the same Walnut cabinet with Satinwood veneers.
The inexpensive and simple drop-type changer "10-12" was introduced by Capehart in 1931. It was used in coin operating models like model Junior 5 (sometimes simply called model 5) or without coin operation but otherwise the same is model 6 and cheaper model 1000. The changer can also be found in some radio consoles like model 15 (TRF) and model 15S (superhet in same cabinet), model 20 (TRF) and model 20S (superhet). Hopefully folders or ads will be found for completing the list.
- Price in first year of sale
- 395.00 $
- External source of data
- Ernst Erb
- Mentioned in
- Radio Collector`s Guide 1921-1932 (page 201)
