Gabbiano RV331

Gabbiano RV331; CGE - Compagnia (ID = 2130753) Radio
Gabbiano RV331; CGE - Compagnia (ID = 1011482) Radio Gabbiano RV331; CGE - Compagnia (ID = 314498) Radio
Gabbiano RV331; CGE - Compagnia (ID = 314499) Radio Gabbiano RV331; CGE - Compagnia (ID = 1011483) Radio
Gabbiano RV331; CGE - Compagnia (ID = 1011486) Radio Gabbiano RV331; CGE - Compagnia (ID = 1064509) Radio
Gabbiano RV331; CGE - Compagnia (ID = 1418695) Radio
Use red slider bar for more.
Gabbiano RV331; CGE - Compagnia (ID = 1011482) Radio
CGE - Compagnia: Gabbiano RV331 [Radio] ID = 1011482 800x430
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gabbiano RV331, CGE - Compagnia Generale di Elettricità; Milano

Country:  Italy
Manufacturer / Brand:  CGE - Compagnia Generale di Elettricità; Milano
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EL84 UY85
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Gabbiano RV331 - CGE - Compagnia Generale di
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 380 x 200 x 170 mm / 15 x 7.9 x 6.7 inch
Notes Mobile in plastica in 3 varianti di colore. Gamme d'onda: medie, TV, FM.
3 colour versions. Wave bands: BC, TV, FM.
Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Source of data Guida Pratica Antique Radio III (2000)

Model page created by Ettore Rossi. See "Data change" for further contributors.
