T16A-29; Ténor, Compagnie (ID = 263819) Radio
Ténor, Compagnie: T16A-29 [Radio] ID = 263819 751x452
Select picture or schematic to display from thumbnails on the right and click for download.
For model T16A-29, Ténor, Compagnie Commerciale de Radio-Électricité (CCR, C.C.R.); Paris

Country:  France
Manufacturer / Brand:  Ténor, Compagnie Commerciale de Radio-Électricité (CCR, C.C.R.); Paris
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: AK2 AF3 ABC1 AL4 AZ1
Main principle Superheterodyne (common); ZF/IF 118 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 22 cm = 8.7 inch
Power out
from Radiomuseum.org Model: T16A-29 - Ténor, Compagnie Commerciale
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 555 x 303 x 200 mm / 21.9 x 11.9 x 7.9 inch
Notes

This model is comparable to Siera S16A.

Net weight (2.2 lb = 1 kg) 11.1 kg / 24 lb 7.2 oz (24.449 lb)

Model page created by Karlheinz Gützlaff. See "Data change" for further contributors.
