M917

M917; Damaiter marca / (ID = 638099) Radio
M917; Damaiter marca / (ID = 2523266) Radio M917; Damaiter marca / (ID = 2523273) Radio
M917; Damaiter marca / (ID = 2523267) Radio M917; Damaiter marca / (ID = 2523270) Radio
Use red slider bar for more.
M917; Damaiter marca / (ID = 2523266) Radio
Damaiter marca /: M917 [Radio] ID = 2523266 1234x854
Select picture or schematic to display from thumbnails on the right and click for download.
For model M917, Damaiter (marca / brand); ved. le note / see text:
ebay.com_283874469155 seller gianfrancom123

Country:  Italy
Manufacturer / Brand:  Damaiter (marca / brand); ved. le note / see text
Year: 1950 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6TE8 6SK7 6SQ7 6V6GT 5Y3GR
Main principle Superheterodyne (common); ZF/IF 471 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 140; 160; 175; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: M917 - Damaiter marca / brand; ved.
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes Gamme d'onda: 2 medie e 2 corte.
Wave bands: 2× BC, 2× SW.

Model page created by Alessandro De Poi. See "Data change" for further contributors.



All listed radios etc. from Damaiter (marca / brand); ved. le note / see text
Here you find 26 models, 20 with images and 19 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
