Model 66

Model 66 ; Decca, London (ID = 553817) Radio

Model 66 ; Decca, London (ID = 553818) Radio

Model 66 ; Decca, London (ID = 553819) Radio

Model 66 ; Decca, London (ID = 553820) Radio

Model 66 ; Decca, London (ID = 1027185) Radio

Model 66 ; Decca, London (ID = 1027186) Radio

Model 66 ; Decca, London (ID = 1027187) Radio

Model 66 ; Decca, London (ID = 1027188) Radio

Model 66 ; Decca, London (ID = 1027189) Radio

Model 66 ; Decca, London (ID = 1027190) Radio
Model 66 ; Decca, London (ID = 269531) Radio Model 66 ; Decca, London (ID = 269532) Radio
Model 66 ; Decca, London (ID = 269533) Radio
Use red slider bar for more.
Model 66 ; Decca, London (ID = 269531) Radio
Decca, London: Model 66 [Radio] ID = 269531 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Model 66, Decca, London

Country:  Great Britain (UK)
Manufacturer / Brand:  Decca, London
alternative name

Decca Gramophone || Decca Radio
Year: 1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM34 EL84 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 100-125; 200-250 Volt
Loudspeaker 2 Loudspeakers
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Model 66 - Decca, London
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 590 x 410 x 230 mm / 23.2 x 16.1 x 9.1 inch
Notes Elliptical permanent magnet loudspeaker and electrostatic tweeter.
Collectors' prices
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1225)

Model page created by Klaus Najman. See "Data change" for further contributors.



All listed radios etc. from Decca, London
Here you find 159 models, 113 with images and 90 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
