482 II

482 II; Deso, Dewald & Sohn, (ID = 17238) Radio

482 II; Deso, Dewald & Sohn, (ID = 17239) Radio

482 II; Deso, Dewald & Sohn, (ID = 2516602) Radio
482 II; Deso, Dewald & Sohn, (ID = 1470165) Radio
Use red slider bar for more.
482 II; Deso, Dewald & Sohn, (ID = 1470165) Radio
Deso, Dewald & Sohn,: 482 II [Radio] ID = 1470165 653x490
Select picture or schematic to display from thumbnails on the right and click for download.
For model 482 II, Deso, Dewald & Sohn, Dewald AG; Zürich:
Eigenes Gerät und Bild

Country:  Switzerland
Manufacturer / Brand:  Deso, Dewald & Sohn, Dewald AG; Zürich
Year: 1947/1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH21 ECH21 EBL21 AZ1
Main principle Superheterodyne (common); ZF/IF 470 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 13 cm = 5.1 inch
Power out
from Radiomuseum.org Model: 482 II - Deso, Dewald & Sohn, Dewald AG
Material Wooden case
Dimensions (WHD) 425 x 250 x 192 mm / 16.7 x 9.8 x 7.6 inch
Price in first year of sale 395.00 SFr
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Thali-Schemasammlung und Tungsram-Röhrenbestückung.


All listed radios etc. from Deso, Dewald & Sohn, Dewald AG; Zürich
Here you find 183 models, 109 with images and 150 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
