• Country
• Germany

• Manufacturer / Brand
• Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

• Year
• 1962 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 200897

• Number of Tubes
• 10

• Valves / Tubes
• EF86 EF86 ECC81 ECC81 EAM86 EAM86 ECC83 EL95 EL95 EL95

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch

• Power out
• 2.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: TG12A - Dual, Gebr. Steidinger; St.

• Dimensions (WHD)
• 390 x 340 x 270 mm / 15.4 x 13.4 x 10.6 inch

• Notes
• 4 pistes, vitesses 4.75 / 9.5 19cm/s, diamètre des bobines 18 cm, 4 touches de tonalité, 1 moteur.

• Net weight (2.2 lb = 1 kg)
• 14.5 kg / 31 lb 15 oz (31.938 lb)

• Author
• Model page created by Christian Berthier. See "Data change" for further contributors.
