MK-3332 Studio

• Country
• Germany

• Manufacturer / Brand
• Eben, Franz, Dipl.-Ing.; Dachau

• Year
• 1961–1964

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 75858

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECC83 ECC83 ECC83 ECC85 EM84 ELL80

• Number of Transistors
• 1

• Semiconductors
• TF65 M3 B250C75 B30C600

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 125; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 5 W (undistorted)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: MK-3332 Studio - Eben, Franz, Dipl.-Ing.;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 375 x 210 x 380 mm / 14.8 x 8.3 x 15 inch

• Notes

• Bandgeschwindigkeiten: 4,75, 9,5 und 19 cm/sek., Hinterbandkontrolle, Drei Motoren (2x Wickelmotor, 1x Tonmotor, alle kollektorlos), Geschwindigkeits-Umschaltung über Stufenachse/Gummirad, Mischregler für PU auf Radio/Mikrofon, drei Köpfe (Aufnahme-, Wiedergabe-, Löschkopf). Kompensationsspule gegen Brummeinstreuung bei Wiedergabe.

  Siehe auch Quelle Modell Studio MK3332.

• Net weight (2.2 lb = 1 kg)
• 16 kg / 35 lb 3.9 oz (35.242 lb)

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Mentioned in
• Funkschau (13/1961 S. 377, 378, Gerätevorstellung)

• Documents regarding this model

• Author
• Model page created by Michael Schott. See "Data change" for further contributors.
