RR230b

RR230b; Elektronska (ID = 2064370) Radio
RR230b; Elektronska (ID = 2549580) Radio RR230b; Elektronska (ID = 1994502) Radio
RR230b; Elektronska (ID = 1994503) Radio
Use red slider bar for more.
RR230b; Elektronska (ID = 2549580) Radio
Elektronska: RR230b [Radio] ID = 2549580 1400x966
Select picture or schematic to display from thumbnails on the right and click for download.
For model RR230b, Elektronska Industrija (Ei); Niš:
from my collection

Country:  Yugoslavia
Manufacturer / Brand:  Elektronska Industrija (Ei); Niš
Brand

Ei
Year: 1963 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH81 EF89 EL84 EZ80 EM80
Main principle Superheterodyne (common); ZF/IF 468 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: RR230b - Elektronska Industrija Ei; Niš
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Notes

Unterschied zu RR230a ist das neue Gehäuse und die EF89, die anstatt EBF80 in der Schaltung.

Model page created by Ivan Notev. See "Data change" for further contributors.



All listed radios etc. from Elektronska Industrija (Ei); Niš
Here you find 103 models, 95 with images and 51 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
