• Country
• Bulgaria

• Manufacturer / Brand
• Elprom KB (Kliment Voroshilov Works, Slabotokov zavod); Sofia

• Year
• 1963 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 208298

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• ECH81 ECC85 EF89 EBF89 EM84 ECC83 EL84 EL84

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Power out
• 9 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Simfoniâ - Симфония 10 R-RGP - Р-РГП - Elprom KB Kliment Voroshilov

• Shape
• Tablemodel with Push Buttons.

• Notes

• Wave Bands:
  MW: 520-1600 kHz
  LW: 145-350 kHz
  SW1: 5,8-12 MHz
  SW2: 12-22 MHz
  FM: 64,5-73 MHz

• Author
• Model page created by Vladislav Slavenkov. See "Data change" for further contributors.
