Eumig 3D 385W
Eumig, Elektrizitäts: Eumig 3D 385W [Radio] ID = 622592 800x564
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1957 ? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 7: ECC85 ECH81 EF89 EABC80 EM84 EL84 EZ80 |
|---|
| Main principle | Super-Heterodyne (Super in general); ZF/IF 460/10400 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) 10 FM circuit(s) |
| Wave bands | Broadcast, Long Wave and FM or UHF. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110, 130, 150, 220, 240 Volt |
| Loudspeaker | 3 Loudspeakers |
| Power out | |
| from Radiomuseum.org | Model: Eumig 3D 385W - Eumig, Elektrizitäts und |
| Material | Wooden case |
| Shape | Tablemodel with Push Buttons. |
| Dimensions (WHD) | 480 x 314 x 232 mm / 18.9 x 12.4 x 9.1 inch |
| Notes | 3D-Raumklang durch 2 seitliche Piezo-Hochton-Lautsprecher. Auch mit eingebautem Plattenspieler, siehe Phono Eumig 3D 386W Bei den Seitenlautsprechern handelt es sich gemäss Martin Bottesch, Klosterneuberg, um Piezo-Hochtöner der Marke Kolibri, hergestellt von der Fa. Ing. Richter, Sachsengasse 7, A-3400 Klosterneuburg / Austria. |
| Net weight (2.2 lb = 1 kg) | 9 kg / 19 lb 13.2 oz (19.824 lb) |
| Price in first year of sale | 1'530.00 ATS |
| Collectors' prices | |
| External source of data | E. Erb 3-907007-36-0 |
| Source of data | Radiokatalog Band 2, Ernst Erb |
| Circuit diagram reference | Unterlagen E.Erb |
| Literature/Schematics (1) | -- Original-techn. papers. |
