Excellent TV311

Excellent TV311; Eumig, Elektrizitäts (ID = 111624) Television

Excellent TV311; Eumig, Elektrizitäts (ID = 111625) Television

Excellent TV311; Eumig, Elektrizitäts (ID = 111626) Television
Excellent TV311; Eumig, Elektrizitäts (ID = 283011) Television Excellent TV311; Eumig, Elektrizitäts (ID = 111623) Television
Excellent TV311; Eumig, Elektrizitäts (ID = 283012) Television Excellent TV311; Eumig, Elektrizitäts (ID = 1662730) Television
Excellent TV311; Eumig, Elektrizitäts (ID = 1662731) Television Excellent TV311; Eumig, Elektrizitäts (ID = 1662732) Television
Excellent TV311; Eumig, Elektrizitäts (ID = 1662733) Television Excellent TV311; Eumig, Elektrizitäts (ID = 1662734) Television
Excellent TV311; Eumig, Elektrizitäts (ID = 1662735) Television Excellent TV311; Eumig, Elektrizitäts (ID = 1662736) Television
Use red slider bar for more.
Excellent TV311; Eumig, Elektrizitäts (ID = 283011) Television
Eumig, Elektrizitäts: Excellent TV311 [Television] ID = 283011 680x521
Select picture or schematic to display from thumbnails on the right and click for download.
For model Excellent TV311, Eumig, Elektrizitäts und Metallwaren-Industrie-Gesellschaft mbH; Wien

Country:  Austria
Manufacturer / Brand:  Eumig, Elektrizitäts und Metallwaren-Industrie-Gesellschaft mbH; Wien
Year: 1962 ?? Category: Television Receiver (TV) or Monitor
Valves / Tubes 17: PCC88 PCF80 EF183 EF184 EF80 PCL84 PCL86 ECH83 ECC82 PCL85 PCC85 PL36 PY88 DY87
Main principle Super-Heterodyne (Super in general)
Details
Power type and voltage Alternating Current supply (AC) / 220 / 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Excellent TV311 - Eumig, Elektrizitäts und
Material Wooden case
Dimensions (WHD) 600 x 440 x 385 mm / 23.6 x 17.3 x 15.2 inch
Notes 48cm / 110° Bildröhre 19 AS P4, 2x EF80, 2x PCF80. Kanal 2a - 12, vorbereitet für UHF-Tuner. Raumlichtautomatik mittels Photowiderstand.
Net weight (2.2 lb = 1 kg) 23 kg / 50 lb 10.6 oz (50.661 lb)
Collectors' prices
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
