• Country
• Finland

• Manufacturer / Brand
• Fenno, Helsinki - see also Philips

• Year
• 1956 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 148986

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• ECC85 ECH81 EF85 EF89 EM80 EABC80 EL84 EZ80

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 127-245 Volt

• Loudspeaker
• 3 Loudspeakers

• Power out
• 3 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Kaiku F266V - Fenno, Helsinki - see also

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 670 x 420 x 260 mm / 26.4 x 16.5 x 10.2 inch

• Notes
• Loudspeaker: 8,5" + 2x 5"x 8" dynamic loudspeaker.
  Separate tuning for FM and AM.

• Net weight (2.2 lb = 1 kg)
• 15 kg / 33 lb 0.6 oz (33.04 lb)

• Price in first year of sale
• 47,000.00 FIM

• Source of data
• - - Data from my own collection
