Funkwerk Dresden,: Mende 07 [Radio] ID = 126030 933x536
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1947–1950 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 4: ECH11 EBF11 ECL11 AZ11 |
|---|
| Main principle | Superheterodyne (common) |
|---|---|
| Tuned circuits | 5 AM circuit(s) |
| Wave bands | Broadcast, Long Wave and Short Wave. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110/220 Volt |
| Loudspeaker | Electro Magnetic Dynamic LS (moving-coil with field excitation coil) |
| Power out | |
| from Radiomuseum.org | Model: Mende 07 - Funkwerk Dresden, VEB, RFT |
| Material | Wooden case |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 410 x 230 x 180 mm / 16.1 x 9.1 x 7.1 inch |
| External source of data | E. Erb 3-907007-36-0 |
| Source of data | Radiokatalog Band 2, Ernst Erb |
| Circuit diagram reference | Lange-Nowisch |
