Robuk RG-30

Robuk RG-30; GBC; Milano (ID = 665184) R-Player

Robuk RG-30; GBC; Milano (ID = 665187) R-Player

Robuk RG-30; GBC; Milano (ID = 665189) R-Player

Robuk RG-30; GBC; Milano (ID = 665190) R-Player
Robuk RG-30; GBC; Milano (ID = 665177) R-Player Robuk RG-30; GBC; Milano (ID = 665180) R-Player
Robuk RG-30; GBC; Milano (ID = 665181) R-Player
Use red slider bar for more.
Robuk RG-30; GBC; Milano (ID = 665177) R-Player
GBC; Milano: Robuk RG-30 [R-Player] ID = 665177 748x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Robuk RG-30, GBC; Milano:
Selezione Radio-TV Ottobre 1963

Country:  Italy
Manufacturer / Brand:  GBC; Milano
alternative name

Gian Bruto Castelfranchi
Year: 1963 ?? Category: Sound/Video Recorder and/or Player
Valves / Tubes 5: ECC83 ECL82 EL84 EZ80 EM84
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 220/250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Robuk RG-30 - GBC; Milano
Material Plastics (no bakelite or catalin)
Shape Book-shelf unit.
Dimensions (WHD) 400 x 185 x 290 mm / 15.7 x 7.3 x 11.4 inch
Notes Registratore a nastro professionale HI-FI bobine da 7"
3 Motori
Comandi a tastiera: Avviamento sinistro-Avviamento destro-Stop-Registrazione-Ascolto
Contagiri a numeri, indicatore ottico di registrazione, tasto di pausa
Controllo della registrazione in corso (monitor)
Ingressi: Radio-Fono-Micro
Presa per altoparlante e amplificatore di potenza Prodotto dalla Robuck Electrical Industries ltd, Londra, e commercializzato in Italia da GBC.
Net weight (2.2 lb = 1 kg) 9.9 kg / 21 lb 12.9 oz (21.806 lb)
Price in first year of sale 115'000.00 ITL
Literature/Schematics (1) Selezione Radio-TV Ottobre 1963

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
