• Country
• Italy

• Manufacturer / Brand
• Geloso SA; Milano

• Year
• 1953

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 116488

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 6BE6 6BA6 6AT6 6SN7GT 6E5GT 6V6GT 6V6GT 5V4G

• Main principle
• Superheterodyne (common); ZF/IF 467 kHz

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 140; 160; 220; 280 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 8 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: G701R - Geloso SA; Milano

• Shape
• Chassis only or for «building in»

• Notes
• Gamme d'onda: medie e 6 corte. Venduto in scatola di montaggio. Altoparlante AlNiCo V: Geloso SP250. Nelle foto c'è un esempio di applicazione in mobile console con bar.

  Wave bands: BC and 6x SW. Sold as chassis only. We attach some pictures of an example of application in a console wooden case.

• Mentioned in
• Bollettino Tecnico Geloso (n. 49/50)

• Literature/Schematics (1)
• Catalogo Generale Radioprodotti Geloso 1953

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
