G-346-R

G-346-R; Geloso SA; Milano (ID = 2313580) Radio
G-346-R; Geloso SA; Milano (ID = 1103151) Radio G-346-R; Geloso SA; Milano (ID = 1103153) Radio
G-346-R; Geloso SA; Milano (ID = 1103154) Radio G-346-R; Geloso SA; Milano (ID = 1103155) Radio
G-346-R; Geloso SA; Milano (ID = 1992701) Radio G-346-R; Geloso SA; Milano (ID = 1992702) Radio
G-346-R; Geloso SA; Milano (ID = 1992703) Radio
Use red slider bar for more.
G-346-R; Geloso SA; Milano (ID = 1103151) Radio
Geloso SA; Milano: G-346-R [Radio] ID = 1103151 931x672
Select picture or schematic to display from thumbnails on the right and click for download.
For model G-346-R, Geloso SA; Milano

Country:  Italy
Manufacturer / Brand:  Geloso SA; Milano
Year: 1958 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCC85 UCH81 UBF89 UCL82 DM70
Main principle Superheterodyne (common); ZF/IF 467/10500 kHz
Wave bands Broadcast, more than 2 SW bands plus FM or UHF.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: G-346-R - Geloso SA; Milano
Material Wooden case
Notes Raddrizzatore al selenio. Gruppo AF Geloso n, 2682A, gruppo FM n. 2726

Model page created by Ezio Maniscalco. See "Data change" for further contributors.
