Kornett F27; Graetz, Altena (ID = 1616226) Television
Graetz, Altena: Kornett F27 [Television] ID = 1616226 933x888
Select picture or schematic to display from thumbnails on the right and click for download.
For model Kornett F27, Graetz, Altena (Westfalen):
Das Gerät stand 2013/14 in der Sonderausstellung "Sehnsuchtsjahre" im Sauerland-Museum des HSK.

Country:  Germany
Manufacturer / Brand:  Graetz, Altena (Westfalen)
Year: 1956/1957 Category: Television Receiver (TV) or Monitor
Valves / Tubes 20: PCF80 EF80 EF80 EF80 EF80 PL83 EF80 EH90 ECC82 PCL82 ECC82 PL81 PY81 or PY83 EY86 EBF80 EBF80 EF83 PL82 E88CC MW43-69
Main principle Super-Heterodyne (Super in general); ZF/IF 38900 kHz
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Kornett F27 - Graetz, Altena Westfalen
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 526 x 491 x 449 mm / 20.7 x 19.3 x 17.7 inch
Notes VHF-Band I & III.
Net weight (2.2 lb = 1 kg) 35 kg / 77 lb 1.5 oz (77.093 lb)
Price in first year of sale 868.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1956/57
