Melodia 919

Melodia 919; Graetz, Altena (ID = 39581) Radio

Melodia 919; Graetz, Altena (ID = 39582) Radio

Melodia 919; Graetz, Altena (ID = 39584) Radio

Melodia 919; Graetz, Altena (ID = 39588) Radio

Melodia 919; Graetz, Altena (ID = 39589) Radio

Melodia 919; Graetz, Altena (ID = 1750752) Radio
Melodia 919; Graetz, Altena (ID = 59967) Radio Melodia 919; Graetz, Altena (ID = 68282) Radio
Melodia 919; Graetz, Altena (ID = 68281) Radio Melodia 919; Graetz, Altena (ID = 23970) Radio
Melodia 919; Graetz, Altena (ID = 1350487) Radio Melodia 919; Graetz, Altena (ID = 1350488) Radio
Melodia 919; Graetz, Altena (ID = 1350489) Radio Melodia 919; Graetz, Altena (ID = 1350490) Radio
Melodia 919; Graetz, Altena (ID = 1350491) Radio Melodia 919; Graetz, Altena (ID = 1350611) Radio
Use red slider bar for more.
Melodia 919; Graetz, Altena (ID = 59967) Radio
Graetz, Altena: Melodia 919 [Radio] ID = 59967 850x584
Select picture or schematic to display from thumbnails on the right and click for download.
For model Melodia 919, Graetz, Altena (Westfalen)

Country:  Germany
Manufacturer / Brand:  Graetz, Altena (Westfalen)
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EF89 EABC80 EM84 ECC83 EL84 EL84
Main principle Super-Heterodyne (Super in general); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Melodia 919 - Graetz, Altena Westfalen
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 645 x 375 x 270 mm / 25.4 x 14.8 x 10.6 inch
Net weight (2.2 lb = 1 kg) 13 kg / 28 lb 10.1 oz (28.634 lb)
Price in first year of sale 398.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1960/61
