• Year
  • 1959/1960
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 22227

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Number of Transistors
  • Main principle
  • Superheterodyne (common); ZF/IF 460/6750 kHz
  • Tuned circuits
  • 6 AM circuit(s)     10 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 150; 220 Volt
  • Loudspeaker
  • 3 Loudspeakers
  • Power out
  • 6 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Scerzo 6817 - Graetz, Altena Westfalen
  • Shape
  • Console with Push Buttons.
  • Dimensions (WHD)
  • 1120 x 850 x 420 mm / 44.1 x 33.5 x 16.5 inch
  • Net weight (2.2 lb = 1 kg)
  • 42 kg / 92 lb 8.2 oz (92.511 lb)
  • Price in first year of sale
  • 798.00 DM
  • External source of data
  • Erb
  • Mentioned in
  • - - Manufacturers Literature (Katalog1959)
  • Literature/Schematics (2)
  • -- Original-techn. papers. (Technische Daten)
