- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke)
- Year
- 1962 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 244690
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); Export model
- Tuned circuits
- 6 AM circuit(s) 10 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 125; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: 2147Ph/S - Grundig Radio-Vertrieb, RVF,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 485 x 260 x 280 mm / 19.1 x 10.2 x 11 inch
- Notes
-
Svenska Grundig AB Typ 2147 Ph/S is an export model for Sweden;
See also the similar domestic model 2147Pha
- Net weight (2.2 lb = 1 kg)
- 8.6 kg / 18 lb 15.1 oz (18.943 lb)
- Author
- Model page created by Timo Rantasaari. See "Data change" for further contributors.
