• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke)

• Year
• 1956 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 320380

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 ECH81 EF89 EABC80 EM34 or EM35 EL84

• Number of Transistors

• Semiconductors
• B250C100

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 8 AM circuit(s)     13 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Radio Control (+Remote Wire etc)

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 160; 220 Volt

• Loudspeaker
• 4 Loudspeakers

• Power out
• 6 W (max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 3095 ML - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 675 x 355 x 330 mm / 26.6 x 14 x 13 inch

• Net weight (2.2 lb = 1 kg)
• 16 kg / 35 lb 3.9 oz (35.242 lb)

• Author
• Model page created by Jacky Blaise. See "Data change" for further contributors.
