4035W 2×EC92 + EF89

4035W; Grundig Radio- (ID = 374429) Radio

4035W; Grundig Radio- (ID = 374430) Radio

4035W; Grundig Radio- (ID = 374431) Radio

4035W; Grundig Radio- (ID = 374433) Radio

4035W; Grundig Radio- (ID = 374435) Radio

4035W; Grundig Radio- (ID = 374436) Radio
4035W; Grundig Radio- (ID = 617624) Radio 4035W; Grundig Radio- (ID = 803566) Radio
4035W; Grundig Radio- (ID = 1346109) Radio 4035W; Grundig Radio- (ID = 1346110) Radio
4035W; Grundig Radio- (ID = 2126520) Radio 4035W; Grundig Radio- (ID = 2126521) Radio
4035W; Grundig Radio- (ID = 2223846) Radio 4035W; Grundig Radio- (ID = 2223847) Radio
4035W; Grundig Radio- (ID = 2223848) Radio
Use red slider bar for more.
4035W; Grundig Radio- (ID = 617624) Radio
Grundig Radio-: 4035W [Radio] ID = 617624 550x351
Select picture or schematic to display from thumbnails on the right and click for download.
For model 4035W 2×EC92 + EF89, Grundig (Radio-Vertrieb, RVF, Radiowerke):
2 x ec92

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: EC92 EC92 EF89 ECH81 EM34 or EM35 EAF42 EABC80 EL84
Main principle Super-Heterodyne (Super in general); ZF/IF 468/10700 kHz
Tuned circuits 10 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 160; 220 Volt
Loudspeaker 2 Loudspeakers
Power out 5 W (unknown quality)
from Radiomuseum.org Model: 4035W [2×EC92 + EF89] - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 655 x 427 x 316 mm / 25.8 x 16.8 x 12.4 inch
Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)
Price in first year of sale 398.00 DM
Collectors' prices
Mentioned in Rundfunk- +Fernseh-Kat 1954/55

Model page created by Heribert Jung. See "Data change" for further contributors.
