• Year
  • 1957/1958
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 128199
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 9 AM circuit(s)     15 FM circuit(s)
  • Wave bands
  • Broadcast, more than 2 SW bands plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 160; 220; 240 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Power out
  • 7 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 5088WE - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 670 x 400 x 290 mm / 26.4 x 15.7 x 11.4 inch
  • Notes
  • The wave bands are MW (510-1600Khz), SWI, SWII, SWIII, SWIV and FM (88-108Mhz) . Rectifier: B250 C100. Dial lamps: 4x 6V 0,1A; 2x 7V 0,3A. Three elliptical permanent magnet dynamic speakers: 1 x 10"x5.5", 2 x 5.5"x4". One electrostatic tweeter.
  • Literature/Schematics (1)
  • -- Schematic
