Hastings 2035W/3D/GB; Grundig Ltd., London (ID = 460769) Radio
Grundig Ltd., London: Hastings 2035W/3D/GB [Radio] ID = 460769 933x640
Select picture or schematic to display from thumbnails on the right and click for download.
For model Hastings 2035W/3D/GB, Grundig Ltd., London:
My German built 1955 Grundig Hastings 2035W/3D/GB AM/FM 6 valve radio. This UK spec 2035 has an extra piano key and a second dial lamp above the volume control.

Country:  Great Britain (UK)
Manufacturer / Brand:  Grundig Ltd., London
Year: 1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM80 EL84
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle Super-Heterodyne (Super in general); ZF/IF 468/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 200; 220; 240 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Hastings 2035W/3D/GB - Grundig Ltd., London
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 22.5 x 14.5 x 9.5 inch / 572 x 368 x 241 mm
Notes

Optional (wired) remote control for volume and tone, the Grundig "Majestic Baton", which, within its plug at the rear of the set contains an EC92 valve.

The associated receptacle at the back cover is labelled "Emphasis Control".

Made in Germany. Distributed by Grundig Great Britain Ltd.

Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Price in first year of sale 57.75 GBP
Collectors' prices
Source of data - - Manufacturers Literature

Model page created by Howard Craven. See "Data change" for further contributors.
